ASJ10-LD1C Earth Leakage Relay

  • The measurement of AC-type after-current;

  • The streamer display of current percentage;

  • The setting of rated residual action current;

  • The setting of non-driving time of limitation;

  • Two-pair relay output;

  • Possessing the function of on-the-spot and long-distance testing and resetting.

Contact Us
Features Drawings

Features of ASJ10-LD1C Earth Leakage Relay

Frequency

50Hz±5Hz


Auxiliary power supply
AC110V, AC220V, DC85 ~270V

(permissible error ±10%)


Consumption
≤5W

rcd electrical device

Installation

DIN rail 35mm


Dimension(L*W*H)
85×54×64mm

residual current devices rcds


Drawings of ASJ10-LD1C Earth Leakage Relay

rccb relay residual current devices rcds rcd residual current device rcb electrical switch rccb rcd
